Euromaid Wall Oven Tripping Power on Switchboard – Pimpama

Euromaid Wall Oven Tripping Power on Switchboard – Pimpama

A customer in Pimpama contacted ISB Electrical because their Euromaid wall oven was tripping power on the switchboard. The oven could not be used safely because the electrical protection was operating when the appliance was connected or switched on.

When an oven trips the power at the switchboard, it can be caused by a short circuit, damaged heating element, burnt terminal block, faulty selector switch, damaged wiring, low insulation resistance or moisture inside the appliance. In this case, the electrical connection area was inspected and a serious fault was found at the main connector block.

Inspection and Diagnosis

• Checked the oven power supply and switchboard protection
• Confirmed the Euromaid wall oven was tripping power
• Isolated the appliance before inspection
• Inspected the rear connection area and wiring terminals
• Checked the main connector block condition
• Found burning damage around the connector block
• Found shorted contacts at the main connector block
• Confirmed the oven was unsafe to use until repaired

Fault Found

The fault was caused by the main connector block burning and shorting the contacts. The damaged connector block created an unsafe electrical fault and caused the oven to trip power on the switchboard.

A burnt oven connector block can happen when terminals become loose, overheated or damaged. Once the contacts burn or short together, the oven can trip the circuit breaker or safety switch and may become a fire or electric shock risk.

Repair Required

The damaged main connector block must be replaced, and the affected wiring and terminals must be inspected and repaired as required. After replacement, the oven should be electrically tested before being returned to service.

The customer was advised not to use the Euromaid wall oven until the burnt connector block and shorted contacts are repaired and the appliance has been tested for safe operation.

Common Causes of Oven Tripping Power

• Burnt main connector block
• Shorted wiring contacts
• Loose terminal connection causing overheating
• Faulty fan forced element
• Faulty grill or bake element
• Low insulation resistance in heating elements
• Damaged selector switch or thermostat wiring
• Moisture or contamination inside the oven electrical area
